Descrição
Especificações TécnicasMain board (SMB.003.0X)42 Keys IR controllerBox interno para inclusão de hdd usb para gravaçõesProcessador de 396MHz MIPS CPU128MB DDR400 RAM com Clock de 198Mhz,2MB Serial FlashInput 100V ~240V 50/60HzConsumo de energia: 30W Max / 1W StanbyPorta RS232 para atualização do firmware (tb via usb)DVB-S2 Standard (ETSI EN 302 307)Frequencia: 950Mhz ~2150MhzInput Signal Level: -25dBm ~-65dBmDemodulation: QPSK, 8PSK, 16APSKTransport Stream: MPEG-2 ISO/IEC 13818 Transport Stream SpecificationMPEG Profile Level: MPEG2 SD, MPEG2 HD, H-264/AVC SD, H264/AVC HDLNB Power & Polarisation: Vertical 13.5V, Horizontal 18V, Current: MAX 500maMulti Satellite receiving: 22K switcher, DiSEqC 1.0, DiSEqC1.2, USALConditional Access system: 2 Common Interface SlotsSaídas de audio e vídeo:YPbPr, RCA with CVBS, SCART with CVBS, HDMI(HDCP), Left/Right Analog audio output(RCA), Digital audio output(SPDIF cabo coaxial ou fibra)Aspect Ratio: Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter BoxAudio Decoding: MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2, AC3, AAC, OGGAudio Mode: Stereo/MONO/Left/RightSuporte a gravação:DVR with USB HDD, Time shifting with USB HDDUSB2.0 High Speed HOST1 USB 2.0 PortUSB Media Player to playback the media in USB flash disk or USB HDD or USB Card reader with memory cardFile system: FAT12, FAT16, FAT32, NTFS (only supports first partition)Formatos suportados: JPG, BPM, MP3, WMA, AAC, OGG
